VizionSDK

Introduction

The VizionSDK is a software development kit tailored for C++ developers. It is compatible with both Windows and Linux platforms and is specifically designed to support TechNexion cameras across various environments, including Windows10/11, Ubuntu, NXP-i.MX, NVIDIA-Jetson, and so on. It provides the methods to easily control AR Series Cameras for companies and individuals looking to develop custom applications.

We also offer some SDK options for developers: pyvizionsdk, CSVizionSDK, and vizionsdk_c. The Python package delivers bindings built on the original C++ VizionSDK, with support for multiple Python versions across different platforms. The C# package enables .NET developers to seamlessly integrate VizionSDK capabilities on Windows and Linux systems, supporting .NET Standard 2.0 and compatible .NET frameworks. The C wrapper library offers a C interface for incorporating VizionSDK into C-based applications. For ROS 2 applications, vizionsdk_ros2 provides nodes, launch files, topics, and parameters for integrating VizionSDK cameras into ROS 2 systems.

Supported Cameras

Sensor	MIPI CSI-2 (TEVS, TEVM)	USB3 (VCI)	USB3 (VCS, VCM)	FPD-Link III (VLS-FPD3)	GMSL2 (VLS-GM2, VLM-GM2)
AR0144	✓	✓	✓	✓	✓
AR0145	✓		✓	✓	✓
AR0234	✓	✓	✓	✓	✓
AR0235	✓		✓		✓
AR0246	✓		✓		✓
AR0521	✓	✓	✓	✓	✓
AR0522	✓	✓	✓	✓	✓
AR0544	✓		✓		✓
AR0821	✓	✓	✓	✓	✓
AR0822	✓	✓	✓	✓	✓
AR0830	✓		✓		✓
AR1335	✓	✓	✓	✓	✓
AR2020	✓		✓		✓
